About This Product
Dynamic Heat Control from Napoleon
Dynamic Heat Control is a system for managing the heat produced by the appliance at and around the fireplace. The purpose of Dynamic Heat control is to move the heat away from the fireplace to allow it to circulate more effectively within the living space.
Benefits of Dynamic Heat Control
- Greatly reduces clearances directly above fireplace allowing for TV and or artwork*
- Heat is circulated more consistently through the living space increasing comfort in front of the fireplace
- Increase "real world" efficiency as heat is mored into the room rather than retained inside the enclosure
- Complete flexibility in selection of finishing materials**
*Always check appliance manufacturers’ recommendations to confirm suitability and any special environmental limitations. For valuable or antique items, always refer to expert preservation instructions as some items require specifically controlled temperature and/or humidity.
**In most common installation configurations, some specific installations require special provisions. See minimum clearances to combustible enclosures section of manual linked below for more details. Ensure to strictly adhere to instructions.
Compatible Fireplaces:
- Vector Series
- Luxuria Series (DHC Included with Fireplace)
- Tall Vector Series
- Elevation X Series
Installation Options
Choose from 1 of 4 installation options (see manual below for me details)
1. OPEN ENCLOSURE (enclosure stops short of the ceiling)
Leaves a complete air outlet opening above the enclosure to provide the necessary air circulation path for the Dynamic Heat Control™ system. This has been found to be well accepted with respect to final appearance and offer minimal distraction. It also allows for efficient circulation of air within the room.
This option offers the simplest method for framing and installation. Limit the air outlet opening height to 4” to reduce the risk of items inadvertently falling into the enclosure. The air outlet opening must extend around the entire perimeter, or the entire front face of the enclosure, where the enclosure runs from wall to wall.
2. FRONT OPENING
Requires an air outlet opening to be framed no more than 1.5” below the enclosure top to avoid trapping heat in the upper areas and the air outlet opening centered on the appliance center.
Minimum air outlet opening dimensions must be followed. Framing the air outlet opening lower will overheat the appliance, the enclosure, and finishing material.
3. REAR OPENING
Requires air outlet opening to be framed no more than 1.5" below the enclosure top to avoid trapping heat in the upper areas and centered on the appliance center.
Minimum air outlet opening dimensions must be followed. The opening is required. Framing the rear opening lower will overheat the appliance, the enclosure, and finished material.
4. OPEN ENCLOSURE w/HARD COMBUSTIBLE VALENCE
Similar to installation option 1 with the addition of a hard combustible valence.
Minimum opening dimensions and valence dimensions must be followed. Restricting air movement within the valence area will overheat the appliance, the enclosure and finishing material.
